Keychron Releases Open-Source Hardware Files for Over 100 Keyboard Models

Keychron dropped production-grade hardware design files for more than 100 of its keyboard and mouse models on GitHub, giving the community direct access to the same CAD geometry used to manufacture products shipping to desks worldwide. The release covers cases, plates, keycap models, knobs, encoder mounts, stabilizer housings, and complete mouse shell models across the Q, Q Pro, Q HE, K Pro, K Max, K HE, V Max, and P HE keyboard series, plus the M1 through M7 mice.

Files are hosted in a public repository at github.com/Keychron/Keychron-Keyboards-Hardware-Design in STEP (3D CAD) and DXF (2D plate cutout) formats. Keychron named FreeCAD, Onshape, Fusion360, SolidWorks, AutoCAD, and DraftSight as compatible tools. STEP files occupy a meaningful middle ground: far more editable than mesh formats like STL, though not as directly modifiable as native package formats such as Fusion360's .f3d files. Community members working with basic CAD skills or kit-bashing workflows can still do significant work, and the repository accepts improvements via GitHub pull requests.

The company's CEO made the announcement on Keychron's Discord server, framing the release as more than just a modding resource. "We think that making production hardware files available is a meaningful contribution to the broader hardware and keyboard community," the CEO wrote. Keychron's GitHub README also described the designs as carrying "real educational value," with production-level decisions around mounting systems, tolerances, and component integration all visible in the files.

There is an important licensing distinction worth being precise about: these files are "source-available," not fully open source. The license prohibits commercial use outright and bans unauthorized sublicensing or redistribution of modified designs. Personal projects, educational work, and repair applications are all permitted, but manufacturing derivatives for profit requires Keychron's explicit written permission. A dedicated Open Source Design Center at keychron.com/collections/keychron-open-source offers downloads via a simple email-based checkout.

The release also carries context that goes beyond altruism. A recent production run drew sustained community complaints about double inputs and missed keypresses, and the hardware file release has been widely read as a goodwill gesture aimed at rebuilding trust. Whether or not that was the primary motivation, the timing is hard to ignore.

Keychron already has a substantial open-source track record on the firmware side: its QMK fork on GitHub has accumulated roughly 44,000 forks and more than 1,100 stars. QMK itself supports over 3,000 keyboards across the broader enthusiast ecosystem. Opening up production-grade physical hardware files, however, marks a first for the Cambridge, UK-based company, which has built a portfolio of 40-plus keyboard models since its 2017 founding.

Early community reactions have been warm. One forum commenter captured the prevailing mood: "What a cool initiative … Will be downloading all of this to see just how you define something this complicated for external manufacturing." Others voiced hopes that direct access to design geometry might finally let the community address persistent layout quirks, including Keychron's navigation-key cluster arrangement on compact models. Keyboard repair has also surfaced as a compelling practical application, particularly for boards outside warranty coverage.

With 44,000 QMK forks already on record, the community's appetite for what Keychron is offering here is unlikely to go unsatisfied.
